AreaBFE Black Series Hardshell Rooftop Tent Install on 3rd Gen Tacoma

AreaBFE Black Series Aluminum Hard Shell Rooftop Tent Install & Setup

Step-By-Step Install & Setup for the AreaBFE Black Series Aluminum Hardshell Rooftop Tent (RTT) Roof Rail System

If you’re up to date on your hardshell tents, you’ve likely heard of AreaBFE.

If you’ve been keeping up with the articles on Trail Tacoma, you might’ve seen Mike do an initial review and overview of this tent. This was back when they were branded “Adventure Vehicle Tents”. Now all the tents are branded Area BFE.

This particular article will serve as a complete guide to mounting this tent on just about any vehicle. Of course, this install was on a 3rd Gen Tacoma, but the process is pretty much the same for any car with a roof rail system. Before you install this tent, make sure that your roof rack system can handle the added weight and stress.

Let’s get started!

Find It Online

  • AreaBFE Black Series Aluminum Hardshell Rooftop Tent: Check Price

If there is one company that knows the most information on this RTT, it’s Spirt of 1876. Call Mike and ask him any questions. You will get a much better response and more accurate information than any other vendor online. The Spirt of 1876 has installed many of these tents on toppers, roof racks, roof rack cross bars, and SUVs. Furthermore, Spirit of 1876 has run this tent among many others and will give you their honest opinion on whether or not this is the best option for how you travel.

Unboxing

AreaBFE Black Series Aluminum Hard Shell Rooftop Tent Unboxing

There’s no denying it, this tent is BIG.

The box it comes in is roughly the size of a queen size mattress. The tent arrived promptly and was very well packaged. Above, you can see that it was delivered in good shape and without any significant damage.

AreaBFE Black Series Aluminum Hard Shell Rooftop Tent Unboxing

I removed most of it, but the tent is completely wrapped in a layer of bubble wrap.

Also, the tent has a dedicated cloth cover to further protect it during transit.

Aluminum Hard Shell Rooftop Tent - AreaBFE Black Series

I’ve seen a lot of tents and slept in a few, but this was my first hardshell rooftop tent.

My first impression? I couldn’t believe how cool it was! This thing is super dope.

No complaints so far. This tent looks like it’s going to completely change my truck camping experience.

Hardware

AreaBFE Black Series Aluminum Hard Shell Rooftop Tent Hardware

This tent, like most rooftop tents, comes with all the necessary hardware and tools for install.

If you’re like me (way too excited), you might miss the hardware at first. The ladder comes in a separate box, and within that box, you’ll find all the hardware.

Step 1. Install Grab Handle

Installing Grab Handle for AreaBFE Black Series Aluminum Hard Shell Rooftop Tent

The first step is to install the grab handle.

Above, you can see the Allen bolt and the rectangular washer that fits into the tent’s side channels.

Installing Grab Handle for AreaBFE Black Series Aluminum Hard Shell Rooftop Tent

A closeup of the corner of the AreaBFE tent highlights the channels which run the length of the top and bottom of the tent.

Slide the handle and attached washers into the channel. This can take a few tries as the fit is tight, but do this slowly and carefully, and eventually, the washer will catch properly.

Step-By-Step Install for AreaBFE Black Series Hard Shell Rooftop Tent

I chose to install the handle on the back of the tent, using the AreaBFE logo to help center it.

Technically, you could offset the handle or put it on either side. Might not be a bad idea either if you could get your hands on a few extra handles, to mount 3 total. Just a thought.

Step 2. Install Latches

Installing Latches for AreaBFE Black Series Aluminum Hard Shell Rooftop Tent

Next up, you’ll need to install the latch which helps to keep your tent closed when you’re on the move.

These also feature a locking portion.

Installing Latches for AreaBFE Black Series Aluminum Hard Shell Rooftop Tent

All of the mounts, latches, etc., mount using the channels in the tent.

Separate the latch into its individual pieces and first install the smaller part into the upper channel.

Installing Latches for AreaBFE Black Series Aluminum Hard Shell Rooftop Tent

Install the bottom part next.

Installing Latches for AreaBFE Black Series Aluminum Hard Shell Rooftop Tent

I placed the latch about 4 inches away from the side of the tent. I figured this would make it easier to close than if they were closer to the middle of the tent.

These latches need to align almost perfectly to properly close. Once you’ve got them lined up, tighten down the Allen bolts.

Installing Latches for AreaBFE Black Series Aluminum Hard Shell Rooftop Tent

Finished latch install.

I chose to put the larger half of the latch on the bottom, so the latch swings downward, instead of upwards. This is a personal preference.

Step 3. Install Ladder Mounts

Installing Ladder Mounts - AreaBFE Black Series Aluminum Hard Shell Rooftop Tent

The tent comes with two sets of these. Technically, you only need two, but you might consider mounting a set on each side of the tent.

You can install these anywhere on the tent, but I only put one set on the side next to the passenger rear tire.

Installing Ladder Mounts - AreaBFE Black Series Aluminum Hard Shell Rooftop Tent

Make sure you install these on the bottom channel, otherwise, your ladder mounts will go with the top portion of the clamshell when it opens and you won’t be able to use your ladder.

Installing Ladder Mounts - AreaBFE Black Series Aluminum Hard Shell Rooftop Tent

For symmetry’s sake, I installed the ladder to the left and right of the AreaBFE logo on the side.

Step 4. Install Rain Fly Pole Mounts

Installing Rain Fly Pole Mounts - AreaBFE Black Series Aluminum Hard Shell Rooftop Tent

At the time of the install, I didn’t know what these were for.

Once I had the tent on, I realized they were used as the first insertion point of the rain fly.

Like all of the other latches and mounts, these also slide into the bottom channel.

Step 5. Mounting Tent

Complete Install Guide for AreaBFE RTT on 3rd Gen Tacoma

As with many rooftop tents, this one also utilizes these formed metal pieces, which hold the above-seen bolts, and slide into the channels on the underside of the tent.

Make sure you seat the bolts as seen above; there is only one way to install these.

How-To Mount AreaBFE Rooftop Tent on 3rd Gen Toyota Tacoma

We placed the tent on a couple of folding tables and installed these before lifting the tent onto the Tacoma. There are eight total, four per channel.

These tents are pretty heavy. There are 3 different sizes and they weigh around 150lbs.

With the help of a friend, we were able to shoulder press the tent into the air and place it on the roof rack rails on my AluCab. If you don’t feel confident doing the same, you could always try and construct some sort of rooftop tent hoisting system. This might be difficult if your garage is not big enough. My truck doesn’t fit in many garages with this tent on the roof.

Installing an Aluminum Hard Shell Clamshell Rooftop Tent

Anyway, once you muscle up the tent on the roof, you’ll need to orient two bolts on each side per roof rack cross-member or rail.

The kit comes with an adhesive-backed rubber cushion that prevents there from being any metal on metal contact between the tent and rack/rail. This is a nice feature that I haven’t seen before.

You simply peel the backing off of the rubber and attach it to the long metal rectangular mounting piece with multiple holes. There are several holes in this piece to account for the size of the cross-member you’re working with.

As seen above, you’ll line up the holes in the metal piece with the bolts hanging from the tent. Then add a washer and a nut. Tighten down accordingly. I overtightened the mounts, hence the bend in the metal. This isn’t necessary, but this is a heavy tent, and I wanted to be sure it wasn’t going anywhere.

Step 6. Open Tent

Opening AreaBFE Hard Shell Rooftop Tent

Opening the tent could not be any easier.

Open the latches and lightly push on the tent handle to open the tent. Once you open it a little more than a foot, the shocks take over the rest.

From this perspective, you can see everything we installed in the previous steps. The ladder mount, the latches and the handle.

Setting up the AreaBFE Aluminum Hard Shell Rooftop Tent

Above, you can see the opened tent.

The elastic which helps to hold the tent material while closing needs to be pulled down to allow the tent to open completely and to finish the rest of the setup.

Step 7. Attach Shoe/Storage Bag

Shoe & Storage Bag for AreaBFE Aluminum Hard Shell Rooftop Tent

This step, again, couldn’t be any more simple.

The bag has hooks at the end which go into the channels on the side of the tent.

Step 8. Attach Ladder to Mounts

Ladder & Rain Fly Pole Install for AreaBFE RTT

The ladder and rain fly poles look as seen above.

Mounting a Ladder on the AreaBFE Aluminum Hard Shell Tent

The ladder has hooks that grab onto the ladder mounts we installed earlier.

Full Install & Setup Guide for the Aluminum Hard Shell Rooftop Tent by AreaBFE

Ladder mounted onto the tent.

Step 9. Set Rain Fly Poles

Setting Up Rain Fly on AreaBFE Aluminum Hard Shell Rooftop Tent

The rain fly pole end that is straight slides into the mount that was previously installed.

Setting Up Rain Fly on AreaBFE Aluminum Hard Shell Rooftop Tent

The other end, that has a hook, attaches to the holes at the far ends of the rain fly.

You’ll have to bed the poles to get them to fit. That’s it! Not bad, right?

Finished Tent Setup

AreaBFE Black Series Hard Shell Rooftop Tent on Lifted 3rd Gen Tacoma

Closed Tent –  Angled Side View

AreaBFE Black Series Hard Shell Rooftop Tent Install & Setup

Closed Tent – Rear View

AreaBFE Black Series Hard Shell Rooftop Tent Complete Install & Setup

Opened Tent – Rear View

AreaBFe Aluminum Hard Shell Clamshell Rooftop Tent on 3rd Gen Tacoma

Opened Tent – Front View

AreaBFe Aluminum Hard Shell Clamshell Rooftop Tent on 3rd Gen Tacoma

Final Thoughts

How-To Install & Setup Guide for the AreaBFE Black Series Rooftop Tent

Considering the size of this tent, the install is pretty straight forward.

If you follow along with this guide, you shouldn’t run into any issues. Be on the lookout for the complete review and overview after we put this tent through its paces. I’m beyond excited to spend a few nights in this bad boy and see what the hardshell RTT life is really all about!
